Referencing sections from different yaml files
The MWE I attach here (test.schema.archive.yaml and sample.schema.archive.yaml) is giving me back the following error, as checked together to @mnakh : "Cannot read properties of undefined (reading '../upload/raw/sample.schema.archive.yaml')".
@dsikter already commented on inheriting from different files in #924 (closed)
My final aim is to reference a section into itself to create a nested structure for the Sample description.
If I reference sections inside the same file, it works nicely (see below hall.schema.archive.yaml)
I would like to ask in this issue also about the possibility to choose which section to nest among an enumeration. In the specific case shown in hall.schema.archive.yaml, I wish I could choose either Sample or Substance every time I take a nesting step. Note that Substance hasn't got a "composition" and it is hence closing the nesting because we arrived down to the elementary constituents.
test.schema.archive.yaml
definitions:
name: 'Eln test inherit Sample class'
sections: # Schemas consist of section definitions
Hall_measurement:
base_section: nomad.datamodel.data.EntryData
sub_sections:
materials:
repeats: true
m_annotations:
eln:
# dict()
section: ../upload/raw/sample.schema.archive.yaml#Sample
sample.schema.archive.yaml
definitions:
name: 'Eln Sample class'
sections: # Schemas consist of section definitions
Sample:
base_section: nomad.datamodel.data.EntryData
quantities:
chemical_name:
type: str
m_annotations:
eln:
component: StringEditQuantity
hall.schema.archive.yaml
definitions:
name: 'Eln inherit Sample class'
sections:
Substance:
base_section: nomad.datamodel.data.EntryData
quantities:
chemical_name:
type: str
m_annotations:
eln:
component: StringEditQuantity
Sample:
base_section: nomad.datamodel.data.EntryData
sub_sections:
composition:
repeats: true
m_annotations:
eln:
section: Sample
quantities:
chemical_name:
type: str
m_annotations:
eln:
component: StringEditQuantity
Hall_measurement:
base_section: nomad.datamodel.data.EntryData
sub_sections:
materials:
repeats: true
m_annotations:
eln:
# dict()
section: Sample
